C20 to 6-15/20R Plug Adapter

1 Foot pigtail allows you to plug a device with a 6-15P or 6-20P plug into a C19 receptacle

SKU: IBX-7779-01

IEC C20 to 6-15/20R Power Cords, Rated 20A/250V 12 AWG


Overview

IEC 60320 power cord with a C20 plug and 6-15/20R connector, rated for 20 amps, 250V.  Features a flexible 12/3 SJT jacket.  Primarily used to connect network and server equipment to a 6-15P or 6-20P power cord plug.


Features

  • IEC C20 male plug to 6-15/20R female connector
  • 1 Foot Length
  • SJT jacket
  • Rated for 20 Amps and 250 Volts
  • 12/3 AWG wire

Specifications

Plug     IEC C20
Connector NEMA 6-15/20R
Voltage 250V
Amps 20A
Length 1 Foot
Jacket Type 12/3 SJT
Color Black

  * SJT jacket is thicker but less flexible compared to the SVT jacket.

  UL and CSA Listed, ROHS approved


Application Shots

5-15 pc power cable
