C20 to L5-30R Plug Adapter Power Cord

1 Foot pigtail allows you to plug a device with an L5-30P plug to a C19 receptacle

SKU: IBX-1055-01

IEC C20 to L5-30R Power Cords, Rated 20A/125V 12 AWG


Overview

IEC 60320 power cord with a C20 plug and L5-30R connector, rated for 20 amps, 125V.  Features a flexible 12/3 SJT jacket.  Primarily used to connect network and server equipment to a L5-30P power cord plug.


Features

  • IEC C20 male plug to L5-30R female connector
  • 1 Foot Length
  • SJT jacket
  • Rated for 20 Amps and 125 Volts
  • 12/3 AWG wire

Specifications

Plug     IEC C20
Connector NEMA L5-30R
Voltage 125V
Amps 20A
Length 1 Foot
Jacket Type 12/3 SJT
Color Black

  * SJT jacket is thicker but less flexible compared to the SVT jacket.

  UL and CSA Listed, ROHS approved


Application Shots
